Full BLDG5 schedule loaded · positions remain adjustable

Plan contrast

Live estimate

Scale provisional

Traced distance + 15% pathway allowance + service loops

Placed60

Routes59

Selected device

RACK-01

Office 13

Provisional cable

Black Cat6 CMR2687 ft

White 16/2 CMR189 ft

Black 16/2 CMR293 ft

Black 16/2 outdoor/UV174 ft

White Cat6 CMR305 ft

70V audio load

180W + 25%

AZ-01 · Main Dining

JBL Control 67P/T-WH

45W

6 speakers ×

AZ-02 · Kitchen

Ceiling speaker · TBD

15W

2 speakers ×

Planning assumption · confirm after model selection

AZ-03 · Bar + Private Dining

Surface speaker · TBD

60W

4 speakers ×

Planning assumption · confirm after model selection

AZ-04 · Restrooms

Ceiling speaker · TBD

15W

2 speakers ×

Planning assumption · confirm after model selection

AZ-05 · Exterior / Patio

Outdoor speaker · TBD

45W

3 speakers ×

Planning assumption · confirm after model selection

Connected load180W

Minimum amplifier capacity230W

Across at least five independently controlled 70V zones.

Trace before ordering

Select a device, choose Route Path, then click each conduit or ceiling turn from the rack toward that device.
